90W switching AC-DC adapter desk-top type

Features

Universal AC input/Full range

Ac inlet:C14/C6/C8

Built-in Active PFC Function

No load power consumption<0.075W

Energy efficiency Level VI

Comply with EISA 2007/DOE,NRC,AU GEMS, EU ERP and COC version 5

Class Ⅰ or Class power

Protections:short circuit /Overload/Over Voltage/Over temperature

Fanless design with -10 to +40

Fully enclosed plastic case

LED indicator for power on.

Safer plastic insulation shell design

Product spec



Specification

O/P Voltage

O/P Current

Ripple & Noise(Max.)

Voltage Accuracy

Line Regulation

Load Regulation

O/P Power(max.)

12.0 V

0.1-6.67 A

300 mVp-p

±5%

±1%

±5%

90W

19.0 V

0.1-4.73A

350 mVp-p

±5%

±1%

±5%

90W

24.0 V

0.1-3.75A

350 mVp-p

±5%

±1%

±5%

90W

36.0 V

0.1-2.5A

350 mVp-p

±5%

±1%

±5%

90W

48.0 V

0.1-1.87A

350 mVp-p

±5%

±1%

±5%

90W



All Model List

Rated O/P voltage range (Vdc)

Rated O/P Current range (A)

Max. O/P power (W)

12.0-20.0

0.10-6.67

90.08

20.1-30.0

0.10-4.47

90.00

30.1-54.00

0.10-2.99

90.00



Certificates and approvals

● CB, CE, GS, UL/CUL, FCC, SAA, RCM, CCC, PSE, KC, KCC

Safety standards

  IEC/EN 62368-1, UL/CUL 62368-1,  GB 4943.1,J60950-1(H27),  J62368-1(H30), AS/NZS 60950.1, AS/NZS 60065, K60950-1

EMC standards

  EMI standards EN55032, FCC Part15 Subpart B, ANSI C63.4

  EMS standardsEN55024, EN55035, EN61000-3-2, EN61000-3-3
